Description
| SIZE | PR | PATTERN R-1 |
STANDARD RIM | TREAD DEPTH MM |
OVERALL DIAMETER MM |
SECTION WIDTH MM |
RELEVANT PRESSURE KPA |
MAX LOADING KG |
| 5.00-12TT | 6 | R1 | 4.00E | 15 | 490 | 145 | 250 | 405 |
| 5.50-17TT | 6 | R1 | 4.50E | 13 | 720 | 150 | 250 | 520 |
| 6.00-12TT | 6 | R1 | 4.50E | 22 | 640 | 165 | 250 | 405 |
| 6.00-14 TT | 8 | R1 | 4.50E | 18 | 690 | 165 | 250 | 685 |
| 6.00-16 TT | 8 | R1 | 4.50E | 18 | 745 | 165 | 250 | 975 |
| 6.50-16TT | 6 | R1 | 5.00F | 25 | 765 | 180 | 250 | 565 |
| 7.00-16 TT | 8 | R1 | 5.00F | 25 | 785 | 180 | 250 | 665 |
| 7.50-16 TT | 8 | R1 | 5.00F | 25 | 910 | 205 | 250 | 760 |
| 7.50-20TT | 6 | R1 | 5.50F | 26 | 910 | 205 | 210 | 760 |
| 8-16TT | 6 | R1 | 6.0-16 | 26 | 790 | 210 | 210 | 615 |
| 8-18TT | 6 | R1 | 6.0-16 | 26 | 900 | 205 | 300 | 750 |
| 8.3-16TT | 4 | R1 | W7 | 26 | 845 | 205 | 210 | 665 |
| 8.3-20TT | 6 | R1 | W7 | 26 | 895 | 210 | 240 | 695 |
| 8.3-24TT | 6 | R1 | W7 | 26 | 995 | 210 | 240 | 810 |
| 9.5-16TT | 6 | R1 | W8 | 23 | 860 | 240 | 210 | 800 |
| 9.5-20TT | 6 | R1 | W8 | 33 | 950 | 240 | 210 | 810 |
| 9.5-24TT | 8 | R1 | W8 | 30 | 1050 | 240 | 280 | 1110 |
| 9.5-28TT | 8 | R1 | W8 | 33 | 1150 | 240 | 280 | 1115 |
| 10.00-15 | 8 | R1 | 8LB | 19 | 855 | 276 | 240 | 1425 |
| 10/75-15.3TL | 10 | R1 | 9 | 22 | 760 | 264 | 390 | 1090 |
| 11.2-20TT | 8 | R1 | W10 | 33 | 1005 | 285 | 240 | 1085 |
| 11.2-24TT | 8 | R1 | W10 | 33 | 1105 | 285 | 240 | 1225 |
| 11.2-28TT | 8 | R1 | W10 | 34 | 1205 | 285 | 240 | 1305 |
| 11.2-38TT | 8 | R1 | W10 | 46.5 | 1540 | 305 | 180 | 1630 |
| 12.4-24TT | 8 | R1 | W11 | 36 | 1160 | 315 | 230 | 1415 |
| 12.4-28TT | 8 | R1 | W11 | 36 | 1260 | 315 | 230 | 1510 |
| 12.4-32TT | 6 | R1 | W11 | 36 | 1360 | 315 | 170 | 1355 |
| 12-38TT | 10 | R1 | DW11 | 35 | 1575 | 330 | 220 | 1800 |
| 13.6/12-38TT | 10 | R1 | W12 | 35 | 1565 | 345 | 250 | 2215 |
| 13.6-24TT | 8 | R1 | W12 | 37 | 1210 | 345 | 210 | 1545 |
| 13.6-28TT | 10 | R1 | W12 | 33 | 1310 | 345 | 250 | 1910 |
| 14.9-24TT | 10 | R1 | W13 | 39 | 1265 | 378 | 230 | 1990 |
| 14.9-26TT | 8 | R1 | W13 | 38 | 1315 | 378 | 180 | 1820 |
| 14.9-28 TT | 10 | R1 | W13 | 38 | 1365 | 378 | 230 | 1880 |
| 14.9-30TT | 10 | R1 | W13 | 38 | 1415 | 378 | 230 | 2190 |
| 15.5/80-24TL | 10 | R1 | W13 | 35 | 1240 | 394 | 400 | 3300 |
| 15.5-38TT | 10 | R1 | W14L | 36 | 1570 | 395 | 230 | 2320 |
| 15-24TT | 10 | R1 | DW14 | 35 | 1330 | 410 | 280 | 2800 |
| 15-24TT | 12 | R1 | DW14 | 35 | 1330 | 410 | 330 | 3100 |
| 16.9-28TT | 10 | R1 | W15L | 39 | 1435 | 430 | 200 | 2380 |
| 16.9-30TT | 10 | R1 | W15L | 40 | 1485 | 430 | 200 | 2455 |
| 16.9-34TT | 10 | R1 | W15L | 39 | 1585 | 430 | 200 | 2605 |
| 16.9-38TT | 10 | R1 | W15L | 39 | 1685 | 430 | 200 | 2760 |
| 18.4-26TT | 12 | R1 | DW16 | 38 | 1450 | 467 | 230 | 2985 |
| 18.4-30TT | 10 | R1 | W16L | 41 | 1550 | 467 | 180 | 2815 |
| 18.4-34TT | 10 | R1 | W16L | 38 | 1655 | 467 | 180 | 2990 |
| 18.4-38TT | 10 | R1 | W16L | 41 | 1755 | 467 | 180 | 3165 |
| 18.4-42TT | 10 | R1 | W16A | 51 | 1857 | 467 | 180 | 3330 |
| 20.8-38TT | 10 | R1 | W18L | 42 | 1835 | 528 | 160 | 3475 |
| 23.1-26TT | 12 | R1 | DW20 | 42 | 1605 | 587 | 170 | 3610 |
| 23.1-30TT | 10 | R1 | DW20 | 42 | 1705 | 625 | 160 | 3750 |
| 24.5-32TT | 12 | R1 | DW21A | 42 | 1805 | 625 | 140 | 4360 |
| 405/70-24TL | 14 | R1 | 13 | 37 | 1075 | 410 | 400 | 3550 |
